Mac初期設定 for フルスタックエンジニア

備忘録。
Railsエンジニア兼iOSエンジニア兼Androidエンジニアな僕がMacを新しく買った時にやること。
構成管理全部自動でできたらいいのに&できそうとは思うけど数年に1回だしなぁ。
秘密鍵とか設定とかはだいたいDropboxに置いてあります。

WebやらApp Storeやらからインストールするもの
・開発以外

・開発系

ターミナルでやること

# terminal
rm ~/.bash_profile
ln -s ~/Dropbox/bash_profile ~/.bash_profile

# vim
echo -e -n ':syntax on\n' >> ~/.vimrc

# ssh
ln -s ~/Dropbox/ssh ~/.ssh

# homebrew
xcode-select --install
/usr/bin/ruby -e "$(curl -fsSL https://raw.githubusercontent.com/Homebrew/install/master/install)"
brew doctor

# nodebrew
curl -L git.io/nodebrew | perl - setup
nodebrew install stable
nodebrew use stable

# rbenv
brew install rbenv ruby-build
rbenv install $(rbenv install -l | grep -v - | tail -1)
rbenv global $(rbenv versions | grep -v - | tail -1)

# Node.js / yarn
brew install yarn

# Vue
yarn global add @vue/cli

# iOS
brew install swiftlint
brew install carthage
brew install blender/homebrew-tap/rome
gem install fastlane

# AWS
brew install awscli
ln -s ~/Dropbox/aws ~/.aws

# VSCode
rm -rf ~/Library/Application\ Support/Code/User/
mkdir Library/Application\ Support/Code/User
ln -s ~/Dropbox/code/* ~/Library/Application\ Support/Code/User/

# VSCode
## 共通系

  • Remote Development

# Ruby(Rails)


# HTML/CSS

  • IntelliSense for CSS, SCSS class names in HTML, Slim and SCSS

# Other

  • vue
  • GraphQL


Xcode10 Abort trap:6

たまには書く。

To iOSえんじにあーな皆様
Xcode10にすると以下のコードが使えなくなる模様だぉ
なんでだかわからんけど、調べる暇はないんだぉ

import UIKit

final class FooViewController: UIViewController {
    init() {
        super.init(nibName: nil, bundle: nil)
    }

    required init?(coder aDecoder: NSCoder) {
        fatalError("init(coder:) has not been implemented")
    }
}

こっちならおっけーらしいけどさーけどさー
convenience initってinitじゃないじゃん?

import UIKit

final class FooViewController: UIViewController {
    convenience init() {
        self.init(nibName: nil, bundle: nil)
    }
}


【Cordova】 bump


プラグインとかあるけど、よくよく考えたら、fastlane使ってりゃRubyで書けばいいよね。
なお、Unity / Cocos2d-x に加え、Cordova pluginの作り方も覚えた。

  lane :bump do
    require 'rexml/document'
    doc = REXML::Document.new(File.read('../config.xml'))
    element = doc.elements['widget']
    element.attributes['android-versionCode'] = element.attributes['android-versionCode'].to_i + 1
    element.attributes['ios-CFBundleVersion'] = element.attributes['ios-CFBundleVersion'].to_i + 1
    File.write('../config.xml', doc)
  end


【WPF】KeyBinding with TriggerAction(Data Binding対応版)

はい。昨日こんなの書きました。動きませんでした。
参考記事によるとTriggerBaseはFreeazableだから、当然TriggerBaseを継承しているやつなら問題ないと思ったんですけどね。ICommandを実装してるとだめらしい。
というわけで書き直しました。

devdevdev.hatenablog.com


InputBindingTrigger

using System;
using System.Diagnostics;
using System.Windows;
using System.Windows.Input;
using System.Windows.Interactivity;

namespace Hoge.Trigger
{
    public class InputBindingTrigger : TriggerBase<FrameworkElement>
    {
        public static readonly DependencyProperty InputBindingProperty =
            DependencyProperty.Register("InputBinding", typeof(InputBinding) , typeof(InputBindingTrigger) , new UIPropertyMetadata(null));

        public InputBinding InputBinding
        {
            get => (InputBinding)GetValue(InputBindingProperty);
            set => SetValue(InputBindingProperty, value);
        }

        private InputBindingCommand command = new InputBindingCommand();

        protected override void OnAttached()
        {
            if (InputBinding == null)
            {
                base.OnAttached();
                return;
            }

            InputBinding.Command = command;
            command.OnExecute += Command_OnExecute;
            if (AssociatedObject.Focusable)
                AssociatedObject.InputBindings.Add(InputBinding);
            else
            {
                FrameworkElement root = null;
                AssociatedObject.Loaded += delegate
                {
                    root = GetRootElement(AssociatedObject);
                    if (!root.InputBindings.Contains(InputBinding))
                        root.InputBindings.Add(InputBinding);
                };
                AssociatedObject.Unloaded += delegate
                {
                    root.InputBindings.Remove(InputBinding);
                };
            }
            base.OnAttached();
        }

        private FrameworkElement GetRootElement(FrameworkElement frameworkElement)
        {
            var parent = frameworkElement.Parent as FrameworkElement;
            if (parent == null)
            {
                Debug.Assert(frameworkElement.Focusable);
                frameworkElement.Focus();
                return frameworkElement;
            }
            return GetRootElement(parent);
        }

        protected override void OnDetaching()
        {
            command.OnExecute -= Command_OnExecute;
            base.OnDetaching();
        }

        private void Command_OnExecute(object parameter) => InvokeActions(parameter);
    }

    internal class InputBindingCommand : ICommand
    {
        public event EventHandler CanExecuteChanged = delegate { };

        public Action<object> OnExecute = delegate { };

        public bool CanExecute(object parameter) => true;

        public void Execute(object parameter) => OnExecute.Invoke(parameter);
    }
}

ICommandを実装するのやめただけですね。
あと、RootElement取得するように変えてるっす。ので、ちょっとxamlが変わります。
ルート要素のFocusableをTrueに。
TriggerActionはTrigger.Actionsに。
なお、TriggerActionは前回用意したやつなので省略。



<Window x:Class="Hoge.Views.MainWindow"
                 xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
                 xmlns:i="http://schemas.microsoft.com/expression/2010/interactivity"
                 xmlns:action="clr-namespace:Hoge.Action"
                 xmlns:trigger="clr-namespace:Hoge.Trigger"
                 Focusable="True">
    <Grid>
        <i:Interaction.Triggers>
            <trigger:InputBindingTrigger>
                <trigger:InputBindingTrigger.InputBinding>
                    <KeyBinding Modifiers="Ctrl" Key="N"/>
                </trigger:InputBindingTrigger.InputBinding>
                <trigger:InputBindingTrigger.Actions>
                    <action:ShowFolderBrowserDialogAction Description="選択せーや"
                                                                                       SelectedPath="{Binding SelectedPath.Value, Mode=OneWayToSource}" />
                </trigger:InputBindingTrigger.Actions>
            </trigger:InputBindingTrigger>
        </i:Interaction.Triggers>
    </Grid>
</Window>


参考:
qiita.com

【WPF】KeyBinding with TriggerAction

追記。これ、このままじゃData Binding動かへん。書き直します。。


KeyBindingで実行対象がCommandなら別になんてことないんですけどね。
TriggerAction使う場合ね。


いつも通りおもむろに以下を作りましょう。

using System;
using System.Windows;
using System.Windows.Input;
using System.Windows.Interactivity;

namespace Hoge.Action
{
    public class InputBindingTrigger : TriggerBase<FrameworkElement>, ICommand
    {
        public static readonly DependencyProperty InputBindingProperty =
            DependencyProperty.Register("InputBinding", typeof(InputBinding) , typeof(InputBindingTrigger) , new UIPropertyMetadata(null));

        public InputBinding InputBinding
        {
            get => (InputBinding)GetValue(InputBindingProperty);
            set => SetValue(InputBindingProperty, value);
        }

        public event EventHandler CanExecuteChanged = delegate { };

        protected override void OnAttached()
        {
            if (InputBinding != null)
            {
                InputBinding.Command = this;
                AssociatedObject.InputBindings.Add(InputBinding);
            }
            base.OnAttached();
        }

        public bool CanExecute(object parameter) => true;

        public void Execute(object parameter) => InvokeActions(parameter);
    }
}



使い方

こんなTriggerActionが用意してあります。フォルダ選択ダイアログですね。

namespace Hoge.Action
{
    /// <summary>
    /// FolderBrowserDialog Confirmation
    /// </summary>
    public sealed class FolderBrowserDialogConfirmation : Confirmation
    {
        public Boolean? ShowNewFolderButton { get; set; }
        public String SelectedPath { get; set; }
        public Environment.SpecialFolder? RootFolder { get; set; }
        public String Description { get; set; }
        public Object Tag { get; set; }
    }

    /// <summary>
    /// FolderBrowserDialog表示アクション
    /// </summary>
    public sealed partial class ShowFolderBrowserDialogAction
    {
        public Boolean? ShowNewFolderButton
        {
            get => (Boolean?)GetValue(ShowNewFolderButtonProperty);
            set => SetValue(ShowNewFolderButtonProperty, value);
        }
        private static readonly DependencyProperty ShowNewFolderButtonProperty = DependencyProperty.Register("ShowNewFolderButton", typeof(Boolean?), typeof(ShowFolderBrowserDialogAction), new PropertyMetadata(null));

        public String SelectedPath
        {
            get => (String)GetValue(SelectedPathProperty);
            set => SetValue(SelectedPathProperty, value);
        }
        private static readonly DependencyProperty SelectedPathProperty = DependencyProperty.Register("SelectedPath", typeof(String), typeof(ShowFolderBrowserDialogAction), new PropertyMetadata(null));

        public Environment.SpecialFolder? RootFolder
        {
            get => (Environment.SpecialFolder)GetValue(RootFolderProperty);
            set => SetValue(RootFolderProperty, value);
        }
        private static readonly DependencyProperty RootFolderProperty = DependencyProperty.Register("RootFolder", typeof(Environment.SpecialFolder), typeof(ShowFolderBrowserDialogAction), new PropertyMetadata(null));

        public String Description
        {
            get => (String)GetValue(DescriptionProperty);
            set => SetValue(DescriptionProperty, value);
        }
        private static readonly DependencyProperty DescriptionProperty = DependencyProperty.Register("Description", typeof(String), typeof(ShowFolderBrowserDialogAction), new PropertyMetadata(null));

        public Object Tag
        {
            get => GetValue(TagProperty);
            set => SetValue(TagProperty, value);
        }
        private static readonly DependencyProperty TagProperty = DependencyProperty.Register("Tag", typeof(Object), typeof(ShowFolderBrowserDialogAction), new PropertyMetadata(null));
    }

    public sealed partial class ShowFolderBrowserDialogAction : TriggerAction<DependencyObject>
    {
        private static readonly FolderBrowserDialogConfirmation NullObject = new FolderBrowserDialogConfirmation();

        protected override void Invoke(object parameter)
        {
            var param = parameter as InteractionRequestedEventArgs;
            var confirmation = param == null ? NullObject : param.Context as FolderBrowserDialogConfirmation;

            var dialog = GenerateDialog(confirmation);
            if (dialog.ShowDialog() == DialogResult.OK)
            {
                confirmation.Confirmed = true;
                ApplyDialogPropertyValues(confirmation, dialog);
            }
            else
            {
                confirmation.Confirmed = false;
            }

            param?.Callback();
        }

        private FolderBrowserDialog GenerateDialog(FolderBrowserDialogConfirmation confirmation)
        {
            var dlg = new FolderBrowserDialog();
            dlg.ShowNewFolderButton = confirmation.ShowNewFolderButton ?? ShowNewFolderButton ?? dlg.ShowNewFolderButton;
            dlg.RootFolder = confirmation.RootFolder ?? RootFolder ?? dlg.RootFolder;
            dlg.Description = confirmation.Description ?? Description ?? dlg.Description;
            dlg.Tag = confirmation.Tag ?? Tag ?? dlg.Tag;
            SelectedPath = string.Empty;
            return dlg;
        }

        private void ApplyDialogPropertyValues(FolderBrowserDialogConfirmation n, FolderBrowserDialog dlg)
        {
            if (n != NullObject)
            {
                n.ShowNewFolderButton = dlg.ShowNewFolderButton;
                n.SelectedPath = dlg.SelectedPath;
                n.RootFolder = dlg.RootFolder;
                n.Description = dlg.Description;
                n.Tag = dlg.Tag;
            }

            ShowNewFolderButton = dlg.ShowNewFolderButton;
            SelectedPath = dlg.SelectedPath;
            RootFolder = dlg.RootFolder;
            Description = dlg.Description;
            Tag = dlg.Tag;
        }
    }
}


んで、xaml。コードビハインドとViewModelは省略。ReactiveProperty使ってます。

<Window x:Class="Hoge.MainWindow"
                 xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
                 xmlns:i="http://schemas.microsoft.com/expression/2010/interactivity"
                 xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
                 xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
                 xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
                 xmlns:action="clr-namespace:HogeAction"
                 mc:Ignorable="d" d:DesignHeight="450" d:DesignWidth="800">
    <Grid>
        <i:Interaction.Triggers>
            <action:InputBindingTrigger>
                <action:InputBindingTrigger.InputBinding>
                    <KeyBinding Modifiers="Ctrl" Key="N"/>
                </action:InputBindingTrigger.InputBinding>
                <action:ShowFolderBrowserDialogAction Description="フォルダを選択してください"
                                                                                   SelectedPath="{Binding SelectedPath.Value, Mode=OneWayToSource}" />
            </action:InputBindingTrigger>
        </i:Interaction.Triggers>
        <Grid.RowDefinitions>
            <RowDefinition Height="Auto" />
            <RowDefinition />
        </Grid.RowDefinitions>
        <Menu Grid.Row="0" >
            <MenuItem Header="ファイル(_F)">
                <MenuItem Header="新規(_N)" InputGestureText="Ctrl+N">
                    <i:Interaction.Triggers>
                        <i:EventTrigger EventName="Click">
                            <action:ShowFolderBrowserDialogAction Description="フォルダを選択してください"
                                                                                               SelectedPath="{Binding SelectedPath.Value, Mode=OneWayToSource}" />
                        </i:EventTrigger>
                    </i:Interaction.Triggers>
                </MenuItem>
            </MenuItem>
        </Menu>
    </Grid>
</Window>

【C#】【Google Cloud Vision API】拡張

何に使うのかはわからない。
とりあえずSelectManyの繰り返しがひどかったので用意してみた。
何に使うのかはわからない。
ぶっちゃけTextAnnotationの仕様がよくわかってない。。
TextAnnotation.Text.Split('\n')とBlocks.Textが一致してほしいんだけどなぁ。。



using Google.Cloud.Vision.V1;
using System.Linq;

public static class CloudVisionEx
{
    // TextAnnotation → Page → Block → Paragraph → Word → Symbol → Text

    public static Block[] Blocks(this TextAnnotation textAnnotation) => textAnnotation.Pages.SelectMany(x => x.Blocks).ToArray();

    public static Paragraph[] Paragraphs(this TextAnnotation textAnnotation) => textAnnotation.Pages.SelectMany(x => x.Paragraphs()).ToArray();

    public static Paragraph[] Paragraphs(this Page page) => page.Blocks.SelectMany(x => x.Paragraphs).ToArray();

    public static Word[] Words(this TextAnnotation textAnnotation) => textAnnotation.Pages.SelectMany(x => x.Words()).ToArray();

    public static Word[] Words(this Page page) => page.Blocks.SelectMany(x => x.Words()).ToArray();

    public static Word[] Words(this Block block) => block.Paragraphs.SelectMany(x => x.Words).ToArray();

    public static Symbol[] Symbols(this TextAnnotation textAnnotation) => textAnnotation.Pages.SelectMany(x => x.Symbols()).ToArray();

    public static Symbol[] Symbols(this Page page) => page.Blocks.SelectMany(x => x.Symbols()).ToArray();

    public static Symbol[] Symbols(this Block block) => block.Paragraphs.SelectMany(x => x.Symbols()).ToArray();

    public static Symbol[] Symbols(this Paragraph paragraph) => paragraph.Words.SelectMany(x => x.Symbols).ToArray();

    public static string[] Text(this TextAnnotation textAnnotation) => textAnnotation.Pages.SelectMany(x => x.Text()).ToArray();

    public static string[] Text(this Page page) => page.Blocks.SelectMany(x => x.Text()).ToArray();

    public static string[] Text(this Block block) => block.Paragraphs.Select(x => x.Text()).ToArray();

    public static string Text(this Paragraph paragraph) => string.Join(string.Empty, paragraph.Words.Select(x => x.Text()));

    public static string Text(this Word word) => string.Join(string.Empty, word.Symbols.SelectMany(x => x.Text));
}

【WPF】親からの比率でいろいろ指定したい、Data Binding, Prism, Reactive

ずーっと何年もこのブログのアクセスランキングTOP5は全部C#の記事なんですぉ。
ということでたまにはC#だぉ。


はい、表題の通り。例えば親の幅の半分の幅にしたいとかいうことあるよね。
Gridとかならさあれだけどさ。Canvas想定ね、Canvas
親のActualWidthを取ってこないとだめなケースの場合に使えるかと?VMでそんなもん持ちたくないやん?

はい、いつも通りおもむろに以下のクラスを作りましょう。OneWay前提なのでConvertBackは適当。

using System;
using System.Globalization;
using System.Windows.Data;

namespace Hoge.Converter
{
    public sealed class RatioConverter : IMultiValueConverter
    {
        public object Convert(object[] values, Type targetType, object parameter, CultureInfo culture)
            => (double)values[0] * (double)values[1];

        public object[] ConvertBack(object value, Type[] targetTypes, object parameter, CultureInfo culture)
            => null;
    }
}

で、VM

using Prism.Mvvm;
using Reactive.Bindings;
using Reactive.Bindings.Extensions;

namespace Hoge.Controls
{
    /// <summary>
    /// View model for HogeControl
    /// </summary>
    public sealed partial class HogeControlVM:  BindableBase
    {
        public ReadOnlyReactiveProperty<double> WidthRatioProperty { get; }
        private double Width { get => width; set => SetProperty(ref width, value); }
        private double width;
    }

    public partial class HogeControlVM
    {
        public HogeControlVM()
        {
            WidthRatioProperty = this.ObserveProperty(x => x.Width).ToReadOnlyReactiveProperty();
            Width = 0.5;
        }
    }
}



コードビハインドは省略で、View

<UserControl x:Class="Hoge.Controls.HogeControl"
             xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
             xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
             xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
             xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
             xmlns:c="clr-namespace:Hoge.Converter"
             mc:Ignorable="d"
             d:DesignHeight="450" d:DesignWidth="800">
    <UserControl.Resources>
        <c:RatioConverter x:Key="Ratio" />
    </UserControl.Resources>
    <Canvas Name="Canvas">
        <TextBox Text="Hogeeee">
            <TextBox.Width>
                <MultiBinding Converter="{StaticResource Ratio}">
                    <Binding ElementName="Canvas" Path="Width" />
                    <Binding Path="WidthRatioProperty.Value" />
                </MultiBinding>
            </TextBox.Width>
        </TextBox>
    </Canvas>
</UserControl>

IDE使わずに書いてるから動かなかったらごめんちゃい?
